型号
|
PMC-150-4
|
PMC-150-110
|
PMC-150-113
|
PMC-150-210
|
PMC-150-20
|
|
阴极类型
|
-4
|
-110
|
-113
|
-210
|
-20
|
|
波长范围/ nm 1）
|
185-870
|
230-700
|
185-700
|
230-700
|
300-900
|
|
探测器量子效率1）
|
25％
380纳米
|
35％
@ 350纳米
|
43％
@ 350纳米
|
18％
490纳米
|
|
|
光谱灵敏度：单击此处
|
|||||
|
暗计数率（典型值）/ s -1，T case = 22°C
|
20
|
2
|
<1
|
1个
|
200
|
|
渡越时间
（TCSPC IRF / FWHM，典型值）
|
130 ps
|
140 ps
|
|||
|
计数率
|
> 5 MHz（连续），> 100 MHz（峰值，<1 µs）
|
||||
|
单电子响应宽度（FWHM，典型值）
|
1.5纳秒
|
||||
|
单电子响应幅度（V gain = 0.9 V至1 V）
|
100至200 mV
|
||||
|
过载指示器
|
LED和声音信号
|
||||
|
过载信号
|
TTL / CMOS，低电平有效
|
||||
|
信号输出
|
|||||
|
输出极性
|
负
|
||||
|
输出接头
|
SMA
|
||||
|
输出阻抗
|
50Ω
|
||||
|
电源
|
|||||
|
（来自DCC-100卡）
|
+12 V，-12 V（仅风扇），冷却器电流0.5至1 A
|
||||
|
一般信息
|
|||||
|
阴极直径
|
8毫米
|
||||
|
尺寸（宽x高x长）
|
（76 x 111 x 56）毫米
|
||||
|
光学适配器
|
C-Mount 母口
|
||||
|
光纤耦合
|
可根据客户要求提供SMA 905或FC
|
||||
（1）根据Hamamatsu规格
